2025 Orbea Orca M30i
Description
If climbing is your thing, the Orbea Orca M30i was made for you. Built around Orbea's OMR carbon frame, this is a race-focused road bike that rewards every watt you put in — lightweight, stiff where it needs to be, and surprisingly smooth where it counts.
The "i" means electronic shifting — Shimano 105 Di2 running a 12-speed setup that delivers crisp, precise gear changes at the touch of a button. Pair that with hydraulic disc brakes that feel confident in variable conditions, and you've got a bike that performs as well on a rainy descent as it does on a sun-drenched climb.
Internal cable routing runs cleanly under the stem and through the head tube — no rub, no rattle — and the frame is powermeter compatible when you're ready to get serious about your numbers.
This is a rider's bike. One that gets out of the way and lets you ride. Available at Obsession Bikes.
Key Features: OMR Carbon Frame · Shimano 105 Di2 2x12 · Hydraulic Disc Brakes · Internal Cable Routing · Powermeter Compatible · Tubeless Ready
Don't forget your helmet!
Chain
Shimano M6100 12spd
Cassette
Shimano 105 R7100 11-34t 12spd
Breaks
Shimano R7170 Hydraulic Disc
Saddle
Fizik Aliante R5
Seat Post
SP 0.2 Carbon, 27.2mm, Setback 20
Wheelset
Alloy, Tubeless, 700c, 19c, 28H
Front Wheel Axel
Orbea Thru Axle 12x100mm M12x2 P1 Hollow
Rear Wheel Axel
Orbea Thru Axle 12x142mm M12x2 P1 Hollow
TIRES
Vittoria Zafiro V Rigid bead 700x28c
Geometry
Measurements are in millimetres and degrees
| Size | 47 | 49 | 51 | 53 | 55 | 57 | 60 |
|---|---|---|---|---|---|---|---|
| A - Stack | 506 | 515 | 533 | 552 | 572 | 590 | 616 |
| B - Reach | 370 | 375 | 380 | 385 | 391 | 398 | 404 |
| C - Top Tube (EFF) | 510.3 | 522.7 | 535.9 | 548.5 | 560.4 | 576.1 | 590 |
| D - Fork Length | 365 | 365 | 365 | 365 | 365 | 365 | 365 |
| E - Seat Tube (C-T) | 440 | 460 | 480 | 500 | 520 | 540 | 570 |
| F - Standover | 736.5 | 748.5 | 767.5 | 788.5 | 808.5 | 826.5 | 852.5 |
| G - Chainstay | 408 | 408 | 408 | 408 | 408 | 408 | 408 |
| H - Head Tube | 110.5 | 118.2 | 134.6 | 152.9 | 173.1 | 191.2 | 218.3 |
| I - BB Height | 268.5 | 268.5 | 268.5 | 270.5 | 270.5 | 270.5 | 270.5 |
| J - Wheelbase | 971.8 | 975.4 | 980 | 981.2 | 991.4 | 1001.9 | 1015.6 |
| K - Head Tube Angle | 71º | 71.5º | 72.2º | 72.8º | 73º | 73.2º | 73.2º |
